Small Form-Factor Pluggable Long Reach Ethernet over VDSL2

SFP-VDSLAB

Example of Small Form-Factor Pluggable Long Reach Ethernet over VDSL2

Availability: Worldwide

PDF Datasheet: en

icon

Over VDSL

The ComNet SFP-VDSLAB small form-factor pluggable Ethernet extender module kit improves bandwidth and distance of Ethernet over existing VDSL2 technology. It helps avoid installation costs of new fiber lines on site and can extend Ethernet service on UTP wire with distance up to 3,000 meters. Full Duplex 100 Mbps speed can reach up to 400 meters over standard Cat 5e 2-wire cable. The symmetric profile can be used for standard Ethernet connections or the asymmetric profile can support high traffic flow in a single direction.

Housed in a small form-factor pluggable (SFP) module enclosure, it is designed for plug-and-play installation into any 1000BASE-FX Ethernet unit with an MSA-compliant port. These pairs include the SFP-VDSLA module to be installed at one end and the SFP-VDSLB installed in the other.

Please contact ComNet Techincal Support to Confirm Compatibility with specific ComNet Ethernet Products.

Features for SFP-VDSLAB

  • Extends Ethernet up to 1.8 mi (3 km) at 10 Mbps or 1,300 feet (400 m) at 100 Mbps over Cat 5e 2-wire cable.
  • Designed to meet full compliance with the environmental requirements (ambient operating temperature, mechanical shock, vibration, humidity with condensation, high-line/low-line voltage conditions, and transient voltage protection) of NEMA TS-1/TS-2 and the Caltrans Specification for Traffic Signal Control Equipment.

Applications

  • Retrofit existing VDSL2 installations to Ethernet-based systems
  • Metering, Transportation, Outdoor Wi-Fi Access Points, IP Surveillance

SFP-VDSLAB Application Diagram(s) (1)

Application Diagram(s) for SFP-VDSLAB

SFP-VDSLAB Ordering Information

Part NumberDescription
SFP-VDSLABIndustrial Long Reach Ethernet over VDSL2 SFP CO & CPE. Lifetime Warranty.

Distance figures are obtained using in-house testing mirroring installations. Factors such as cable quality, the number of connectors and splices in the cable run, and environmental conditions encountered within the installation might affect the actual transmission distance and should be taken into consideration. See distance/bandwidth table. Please contact ComNet Techincal Support to Confirm Compatibility with specific ComNet Ethernet Products.
