10/100/1000 Mbps Ethernet Media Converters

CNGE2MC Series

Example of 10/100/1000 Mbps Ethernet Media Converters

Availability: NA Only

PDF Datasheet: en
pdfManual
DWG CAD
DOC A&E Specs

icon

INCLUDED ☞

icon

-40 º to +75 ºC

icon

FLEXIBILITY

icon

CONVERTER

icon

1 OR 2

icon

Made in the USA

icon

WARRANTY

The ComNet CNGE2MC and CNGE22MC are one-channel and two-channel, Gigabit Ethernet electrical to optical media converters. These auto-negotiating devices accept a 10/100/1000 Mbps electrical input and convert this to a 1000 Mbps (1Gbs) optical output. These units use ComNet SFPs (small form-factor pluggable) modules for fiber and connector type, and distance. LED indicators confirm operational status. All models are environmentally hardened with no electrical or optical adjustments (Plug and Play). Packaged in the exclusive ComNet ComFit housing, the standard size units may be either wall or rack mounted. The CNGE2MCM is available in a small size package. The units are powered by an included 8-15VDC power supply.

Features for CNGE2MC Series

  • IEEE 802.3 compliant
  • Designed for installation in harsh out-of-plant/ unconditioned industrial or roadside operating environments (-40 º to +75 ºC ambient). Fully compliant with the environmental requirements of NEMA TS-2 for Traffic Signal Control Equipment
  • Full-duplex transmission of 10/100/1000 Mbps Ethernet -10/100/1000 BASE-TX electrical port - 1000 BASE-FX optical port when used with suitable ComNet SFPs
  • Uses customer-installed ComNet SFPs for compatibility with a wide range of optical fibers, optical connector types, and optical transmission distances (SFPs ordered separately).
  • The port count makes this unit ideal for those applications where rack density or shelf-space may be limited.
  • Made in the USA
  • Voltage transient protection on all power and signal input/output lines provides protection from power surges and other voltage transient events.
  • ComFit standard form factor is interchangeable between stand-alone or rack mount use.
  • Status indicating LEDs provide rapid indication of critical operating parameters.
  • Plug-and-play design ensures ease of installation and no electrical or optical adjustments are ever required.
  • Compact form-factor saves space in those installations where space may be at a premium.
  • Electric Port Supports Auto-negotiation for Full Duplex or Half Duplex Data Throughput
  • Lifetime Warranty

CNGE2MC Series Application Diagram(s) (1)

Application Diagram(s) for CNGE2MC Series

CNGE2MC Series Ordering Information

Part NumberDescription
CNGE2MC2 Port (1 Channel) 10/100/1000 Mbps Ethernet Media Converter. Lifetime Warranty.
CNGE2MCMSmall Size 2 Port (1 Channel) 10/100/1000 Mbps Ethernet Media Converter. Lifetime Warranty.
CNGE22MC4 Port (2 Channel) 10/100/1000 Mbps Ethernet Media Converter. Lifetime Warranty.
