Dual AM Video Receiver with Manual Gain Control (AGC)

FVR21

Example of Dual AM Video Receiver with Manual Gain Control (AGC)

Availability: Worldwide

PDF Datasheet: en
pdfManual
DWG CAD
DOC A&E Specs

icon

INCLUDED ☞

icon

-40 º to +75 ºC

icon

1

icon

Made in the USA

icon

WARRANTY

The ComNet FVR21 dual video receiver detects two independent AM video signals in one module on two independent multimode fiber optic cables, utilizing Manual Gain Control (MGC). The module is not a multiplexer. The module is ideal for CCTV installations and the rack mount version can be used to double the fixed video capacity of the C1 rack for up to 28 independent video channels per card cage.

Features

  • Full color compatibility
  • Plug-and-play design ensures ease of installation and no electrical or optical adjustments are ever required.
  • Voltage transient protection on all power and signal input/output lines provides protection from power surges and other voltage transient events.
  • Compatible with NTSC, PAL, or SECAM Video Standards
  • Standard ComFit models are hot-swappable.

Applications

  • CCTV (Fixed Video)

Application Diagram(s) (1)

Application Diagram(s) for FVR21

Ordering Information

Part NumberDescription
FVR21Dual Video Receiver (850 nm)

☞ Power supplies provided in North America only. The power supplies provided with ComNet products are designed for benign 0 º to 50 ºC applications. Hardened power supplies are available; consult the factory to select the right power supply for your application.
