Dual Independent AM Video Receiver with Automatic Gain Control (AGC)

FVR22

Availability: Worldwide

PDF Datasheet: en
pdfManual
DWG CAD
DOC A&E Specs

icon

INCLUDED

icon

-40 º to +75 ºC

icon

2

icon

Made in the USA

icon

WARRANTY

The ComNet FVR22 dual video receiver detects two independent AM video signals in one module on two independent multimode fiber optic cables. The module is not a multiplexer. The module is ideal for smaller CCTV installations and the rack mount version can be used to double the fixed video capacity of the C1 rack for up to 28 independent video channels per card cage. The modules utilize Automatic Gain Control (AGC).

Features

  • Full color compatibility
  • Designed to meet full compliance with the environmental requirements (ambient operating temperature, mechanical shock, vibration, humidity with condensation, high-line/low-line voltage conditions, and transient voltage protection) of NEMA TS-1/TS-2 and the Caltrans Specification for Traffic Signal Control Equipment.
  • AM Video Transmission
  • Plug-and-play design ensures ease of installation and no electrical or optical adjustments are ever required.
  • Voltage transient protection on all power and signal input/output lines provides protection from power surges and other voltage transient events.
  • Compatible with NTSC, PAL, or SECAM Video Standards
  • Standard ComFit models are hot-swappable.

Applications

  • CCTV (Fixed Video)

Application Diagram(s) (1)

Application Diagram(s) for FVR22

Ordering Information

Part NumberDescription
FVR22AGC Dual Video Receiver (850 nm)

The power supplies provided with ComNet products are designed for benign 0 º to 50 ºC applications. Hardened power supplies are available; consult the factory to select the right power supply for your application.
